Nakashima 1738009 24" RH 24" 1 3/4" bore

Nakashima 1738009 24" RH 24" 1 3/4" bore
Nakashima 1738009 24" RH 24" 1 3/4" bore
New
Nakashima 1738009 24" RH 24" 1 3/4" bore
Nakashima 1738009 24" RH 24" 1 3/4" bore
Nakashima 1738009 24" RH 24" 1 3/4" bore
  • Stock: 3
  • Brand: Nakashima Propeller
  • Model: NPC 1738009
  • Weight: 20.50kg
  • Dimensions: 60.00cm x 60.00cm x 20.00cm
Product Views: 135
$2,793.00CAD

Nakashima OEM Series

24 inch diameter, 24 inch pitch, 4 blade propeller.
Machined with 1 3/4" standard taper bore, and 7/16" keyway to fit 1 3/4" diameter prop shafts.
Part Number 1738009. Standard propeller for Bayliner and Meridian yachts
Also fits many other applications.

Manufactured in high strength, corrosion resistant NiBrAl material.
The increased strength allows for thinner blades which increases the propeller performance.
This propeller has 0.65 blade area ratio, suitable for pleasure yachts


If your specifications are not available in the options, or you have any special requirements, please let us know by using the "Ask a Question" tab before you order.

In most cases, inboard propellers are not returnable due to the fact that they are custom machined for your specific vessel.
It is very important to make sure the dimensions are correct before you order.

Dimensions
Diameter24" (inches)
Pitch24" (inches)
RotationRight Hand
No. of Blades4 (four)
Material
NiBrAlHigh strength Nickel Aluminum Bronze. More corrosion resistant than standard manganese bronze.
Bore
SAE standard taper1 3/4" bore with 7/16" keyway
Blade Area Ratio
BAR0.65
